U1 enables enterprises to implement mobile application quickly and cost-effectively, improve enterprises' productivity and competitiveness,and gain a higher return on investment.
An optimal choice for enterprise mobility
Adopting Android 5.1 OS, U1 provides users with easier development, wider application, and simpler operation.
Supporting WCDMA wireless communication, U 1 can transmit mass business data in real time.Users carrying U1 can share business data with the remote management system anytime anywhere.
A professional and high performance device
U1 provides powerful data collection and transmission functions and supports more convenient operation, making mobile application of enterprises more efficient.
Based on full understanding of enterprise mobility, each aspect of U 1, including product design, parts selection, production and testing, is rigorous and strict to ensure that each U 1 device is reliable and durable.
Flexible options of functional modules and accessories
For users’ benefits, fully considers users’ customization requirements so that they can select or customize devices more flexibly according to their business requirements.
| Operating system | Android 5.1 |
| Processor | 1.3GHz quad-core processor |
| Memory | 1G RAM+8G ROM |
| Extended slot | Mini SD card, up to 32 GB, Micro SD slot |
| Physical Parameter | |
| Display screen | 3.5" (320x480) TFT LCD, LED backlight |
| Cameraloptional) | 5 Mega pixel, autofocus lens, LED flash |
| Exit Window | Corning? Gorilla? glass |
| Battery | 3.7 V 4000 mAh rechargeable lithium polymer battery (6000 mAh battery optional) |
| Dimensions | 152 mm x 68 mm x 24 mm |
| Weight | 255g (lstandard battery included) |
| Key | 1 power key, 2 side scanning keys |
| Power adapter | Input: AC 100 - 220V 50/60Hz; Output: DC 5V-2A |
| Notification | Vibrator alerts/LED/Audio notification |
| Interface(optional) | Micro USB |
| Environmental Parameter/IP Rate | |
| Working Temperature | Working:-10°C - 50 °C |
| Storage Temperature | Working:-20°C - 60 °C |
| Electrostatic | ±15kV air discharge, ±8kV direct discharge |
| Relative humidity | 0% - 95%RH |
| Protection grade | IP65 grade |
| Anti-dropping | 1.5m (On concrete ground) |
| Strength of anti-rolling | 0.5m( 1000 rolling by impact force) |
| Communication Data Parameter | |
| WIFI | IEEE 802.11 b/g/n |
| Bluetooth | Bluetooth 4.0 |
| WWAN | 4G: TDD-LTE：B38/B39/B40/B41；FDD-LTE：B1/B3 3G: WCDMA: 2100MHZ, EVDO 800 MHz, TD-SCDMA:B34/39 2G: GSM/GPRS: 850/900/1800/1900 MHz |
| 數據表單 | |||
| U1 User Manual | Rev.N | 2.09MB | 21 次下載 |
| U1 Data Sheet | |||
